GIGABYTE Z890 AORUS ELITE WIFI7
The GIGABYTE Z890 AORUS ELITE WIFI7 is an ATX motherboard for Intel Core Ultra processors using the LGA1851 socket. Its Intel Z890 Express chipset platform includes four DDR5 DIMM sockets and four M.2 connectors with a mix of PCIe 5.0, PCIe 4.0 and SATA support.
For expansion, the board has a CPU-connected PCIe 5.0 x16 slot and two chipset-connected PCIe 4.0 x4 slots. Networking includes Wi-Fi 7, Bluetooth 5.4 and Realtek 2.5GbE LAN. Display outputs and some memory and display capabilities depend on the processor and installed configuration.
The motherboard also provides a rear Thunderbolt 4/USB4 Type-C port, a separate DisplayPort 2.1 output and a front-panel HDMI 1.4 connection. Check processor, memory, case and device requirements when planning a build; the manufacturer notes that memory support and display functionality depend on the processor or configuration.
Specs & Features:
- Brand / Series / Model: GIGABYTE / AORUS / Z890 AORUS ELITE WIFI7
- Chipset: Intel Z890 Express
- CPU Socket / Support: LGA1851; supports Intel Core Ultra processors
- Memory Sockets: 4 × DDR5 DIMM
- Maximum Memory Capacity: Up to 256 GB total; up to 64 GB per DIMM
- Memory Architecture: Dual-channel
- Memory Support: DDR5 5600–9200 MT/s; speeds above 6400 MT/s are overclocked (O.C.). Supports ECC unbuffered memory in non-ECC mode, non-ECC unbuffered memory, XMP and CUDIMM; support depends on CPU and memory configuration.
- PCIe Expansion Slots: 1 × CPU-connected PCIe 5.0 x16; 2 × chipset-connected PCIe 4.0 operating at x4
- Main PCIe Slot: The main PCIe 5.0 slot supports a graphics card or NVMe SSD.
- M.2 Connectors: 4 total: 1 × PCIe 5.0 x4/x2; 2 × PCIe 4.0 x4/x2; 1 × SATA or PCIe 4.0 x4. Supported module sizes vary by connector and include 25110, 22110, 2580 and/or 2280 as specified per slot.
- SATA Connectors: 4 × SATA 6 Gb/s
- RAID Support: NVMe and SATA RAID 0/1/5/10
- Wired Networking: Realtek 2.5GbE LAN; 2.5 Gbps, 1 Gbps or 100 Mbps
- Wireless Networking: Wi-Fi 7; 2.4, 5 and 6 GHz bands; 802.11a/b/g/n/ac/ax/be; 160 MHz 802.11be support. Actual data rates vary and 6 GHz availability depends on local regulations.
- Bluetooth: Bluetooth 5.4
- Display Outputs: 1 × rear USB4/Thunderbolt 4 USB Type-C with DisplayPort and Thunderbolt video; 1 × DisplayPort 2.1, up to 4096 × 2304 at 60 Hz; 1 × front-panel HDMI 1.4, up to 1920 × 1080 at 30 Hz. Up to 3 displays simultaneously. Processor-dependent; single-display maximums are up to 5120 × 2880 at 60 Hz for a Thunderbolt monitor or 3840 × 2160 at 240 Hz for a USB4 Type-C monitor.
- Rear USB: 1 × Thunderbolt 4/USB4 Type-C (up to 40 Gbps with Thunderbolt devices, 20 Gbps with USB4 devices or 10 Gbps with USB 3.2 devices); 2 × USB 3.2 Gen 2 Type-A; 3 × USB 3.2 Gen 1; 4 × USB 2.0/1.1
- Internal USB Headers: 1 × USB 3.2 Gen 2 Type-C; 2 × USB 3.2 Gen 1; 4 × USB 2.0/1.1
- Audio: Realtek ALC1220 codec; HD Audio; 2/4/5.1/7.1-channel support; optical S/PDIF Out; rear line-out supports DSD audio
- Other Rear Connections: 2 × antenna connectors; 1 × RJ-45; 1 × optical S/PDIF; 2 × audio jacks
- Power and Fan Headers: 1 × 24-pin ATX power; 2 × 8-pin ATX 12V power; CPU, system fan and pump headers
- Lighting and Case Headers: 3 × addressable RGB Gen2 headers; 1 × RGB header; front-panel and front-panel audio headers
- TPM Header: TPM header for GC-TPM2.0 SPI V2 module only
- Onboard Controls: Power, reset and Q-Flash Plus buttons; reset and Clear CMOS jumpers
- Firmware and Utility Support: GIGABYTE Control Center, Q-Flash, Q-Flash Plus and Smart Backup support
- Operating System Support: Windows 11 64-bit support
- Form Factor: ATX
- Dimensions: 30.5 × 24.4 cm
A Wi-Fi 7-equipped Z890 ATX motherboard with four M.2 connectors and a mix of PCIe 5.0 and PCIe 4.0 expansion.
Suitable for Intel Core Ultra LGA1851 desktop builds needing DDR5 memory, multiple M.2 storage options and integrated wired and wireless networking.
